Network 8 channel 4Mpix VD-N6408 video recorder

Network 8 channel 4Mpix VD-N6408 video recorder

Network 8 channel 4Mpix VD-N6408 video recorder

2,400.00р.
2,400.00р.
1
  • operating system: Linux
  • Video compression algorithm: H.265 / H.264
  • Number of Channels: 8шт х 4,0 Mpix (IP сетевой вход ) или 4шт х 5,0 Mpix (IP сетевой вход )
  • video Resolution: 1280 * 1024, 1920x1080P,
  • video Output: 1 VGA / HDMI
  • Audio output: 1 channel
  • Maximum frame rate: 240 sec (NTSC), 200 sec (PAL)
  • audio compression: 8kHz * 16bit ADPCM
All specifications
  • Product Code:   VD-N6408

NVR network video recorder is designed to work in IP - systems. With a built-in Linux operating system and has standard H.265 / H.264 video compression algorithms that achieve high definition. It supports 8-megapixel network cameras with a resolution of 4.0 Mpix or 4th network cameras with a resolution of 5.0 Mpix, ONVIF, HDMI and VGA outputs. To store information, you need to connect a hard drive that supports up to 8TB HDD SATA (not included in the kit). You have the ability to view via the Internet, PTZ control, play the recording, set up the system, download files, receive information. There is access via the P2P cloud service: Android; IOS APP MyEye mobile browsing.

DVR
operating system
Linux
Video compression algorithm
H.265 / H.264
Number of Channels
8шт х 4,0 Mpix (IP сетевой вход ) или 4шт х 5,0 Mpix (IP сетевой вход )
video Resolution
1280 * 1024, 1920x1080P,
video Output
1 VGA / HDMI
Audio output
1 channel
Maximum frame rate
240 sec (NTSC), 200 sec (PAL)
audio compression
8kHz * 16bit ADPCM
recording Modes
Manual Installation / motion sensor / alarm / schedule
HDD Interface
8TB 1 x HDD SATA (item does not contain a hard disk)
network interface
RJ45, 10M/100M
network Protocol
Support TCP / IP, UDP, DHCP, DNNS, PPPoE
network capabilities
Support for viewing real-time mobile phone
USB2.0 interface
2 ports
ONVIF (Open Forum Protocols webcasting)
support
power consumption
From 10 to 15 W.
Power
DC 12V/2A (power adapter included)
Network 8 channel 4Mpix VD-N6408 video recorder
